TVLogic LVM-180A
18,5" FullHD LCD Monitor
Article number: 12296436
Der TVLogic LVM-180A ist ein 18,5" FullHD Entry-Level LCD-Monitor mit einer Helligkeit von 500... more
Product information "TVLogic LVM-180A"
Der TVLogic LVM-180A ist ein 18,5" FullHD Entry-Level LCD-Monitor mit einer Helligkeit von 500 nits und einem Kontrastverhältnis von 1000:1. Der Monitor bietet neben seinen 3G-SDI, HDMI und DVI-Eingängen eine Vielzahl an professionellen Features wie 3G-SDI Level A/B, Focus Assist, Waveform, Vectorscope, Audio Level Meter-Anzeige und vielen weiteren.
Hauptmerkmale
- 18,5" FullHD Monitor
- Auflösung 1920 x 1080
- Blickwinkel: 178° / 178°
- Helligkeit: 500 cd/m²
- Kontrastverhältnis: 1000:1
- 3G-SDI / HDMI / DVI Eingänge
- 3G-SDI Ausgang
- Focus Assist, Waveform, Vectorscope, Timecode-Anzeige
- 3G-SDI Level A/B
- Audio Level Meter-Anzeige
- Blue only / Mono
- Zoom 0 - 90%
Lieferumfang
- 1x TVLogic LVM-180A
Technische Daten
Display |
|
Größe | 18,5" |
Auflösung | 1920 x 1080 (16:9) |
Farbtiefe | 16.7M |
Blickwinkel | 178°(H) / 178°(V) |
Helligkeit | 500 cd/m² |
Kotrastverhältnis | 1000:1 |
Bildschirmbereich | 408 (H) x 203 (V) mm |
Eingänge |
|
Analoger Eingang (Composite) | 1x BNC |
3G-SDI A/B Kanal-Eingang | 2x BNC |
HDMI | 1x HDMI |
DVI | 1x DVI |
Ausgänge |
|
Analoger Eingang (Composite) | 1x BNC |
3G-SDI | 1x BNC |
Eingangssignal |
|
3G-SDI | 2.970Gbps |
HD-SDI | 1.485Gbps |
SD-SDI | 270Mb/s |
HDMI | 480i/480p/576i/576p/720p/1080i/1080p/640x480/ 720x400/800x600/1024x768/1280x1024/1366x768 |
DVI Analog | 640x480/720x400/800x600/1024x768/1366x768 |
DVI DP | 640x480/720x400/800x600/1024x768/1366x768 |
SDI Eingangssignal Formate |
|
SMPTE 425M-A/B | 1080p (60/59.94/50/30/29.97/25/24/23.98/30sF/ 29.97sF/25sF/24sF/23.98sF) |
Audio |
|
Audio Ausgang | Analoger Stereo-Kopfhörerausgang |
Lautsprecher | interner Lautsprechcer (Stereo) |
Funktionen |
|
Funktionen | 1:1 Pixel Mapping Modi für SD/HD, 3G-SDI Level A/B, Audio Level Meter Anzeige, Blue Only, Focus Assist, H/V Delay, Key Lock, Marker, Mono, Range Error, Timecode Anzeige, UMD, User Aspect, Scan Modi, Waveform/Vector, X3 Zoom (PBP) |
Untertitel | CC-608 ANC, CC-608 LINE 21, CC-708, CC-KOR, OP42, OP47 |
Kalibrierung | TVLogic-Farbkalibrierungsdienstprogramm, 3D-LUT & einstellbares Gamma, Import von 3D-LUTs anderer Hersteller |
weitere Funktionen |
|
Remote | GPI (RJ45) |
USB | Firmware-Update via USB-Stick |
Ethernet | Ethernet-Control-Unterstützung |
Allgemein |
|
Maße | 442,5 x 309,2 x 65,4 mm (Display ohne Standfuß) 483,5 x 332,9 x 137,5 mm (Display mit Standfuß, Standfuß kann optional bestellt werden) |
Gewicht | ca. 7 kg |
Consultation
Media
Related links to "TVLogic LVM-180A"
The following info about the manufacturer is available...... more
TVLogic
TVlogic ist ein führender Entwickler und Hersteller von High-Performance 4K, FullHD und HD-Video Equipment für den digitalen Rundfunk und professionellen Videomarkt.
Gegründet im März 2002, setzt TVlogic konsequent auf Qualität und Stabilität. Die überragende Bildqualität der High-End-Geräte für Broadcast basiert auf der von TVlogic entwickelten Technologie.
